Description
Brand New 1 horsepower , 3 phase electric motor. Worldwide Electric designs and manufactures motors with quality and reliability in mind. This motor features Class F insulation, fan cooling, a 1.15 service factor, is a premium efficiency motor and rated for inverter duty. Also suitable for 50 hz operation with a 1.0 service factor. All the worldwide TEFC enclosed 56 frame fractional 3 phase motors have a removable base, with a C-face, and shaft slinger to keep moisture and contaminants from the end of the drive-end bearing for longevity.
Electric Motor Specifications
• 1 Horsepower
• 3 Phase
• TEFC Fully Enclosed
• 56C Frame
• 208-230/460 Volt
• 3600 RPM
• Fan Cooled
• Class F Insulation
• C-Face
• Removable Base
• Premium Efficiency / Inverter Rated
• Worldwide Electric Brand
• Shaft Length: Approximately 1 7/8″
• Keyed 5/8″ Diameter Shaft
• Current: AC
• Full Load Amps: 3.0/1.5A (2.76/1.38A)
• 60 HZ
