3/4 HP 1 Phase Farm Duty Electric Motor 1725 RPM 56 Frame 115-230V TEFC FM34-18-56

Description

3/4 horsepower, single phase farm duty, TEFC electric motor, 115/230 volt with rigid base. Worldwide Electric designs and manufactures motors with quality and reliability in mind. This motor features Class F insulation, fan cooling, a 1.15 service factor, a TEFC enclosure, and a manual overload. Designed for 60Hz and is a 56 frame.

Specifications:

• 3/4 Horsepower
• Single Phase
• TEFC Fully Enclosed
• 56 Frame
• Service Factor 1.15
• Class F Insulation
• 115/230 Volts
• 1800 RPM
• Fan Cooled
• Worldwide Electric Brand
• Shaft Length: Approximately 1 7/8″
• Keyed 5/8″ Diameter Shaft
• Current: AC
• Full Load Amps: 10.0/5.0
• 60 HZ
• Shaft Material: 1045 Carbon Steel
• Max Temp: 40 Degrees C
• Weight Approx: 28.5 LBS
