Male Branch Tee 1/2″ Male NPT x 1/2″ Female NPT Brass Union Tee Pipe Connector

Description

1/2″ FNPT x 1/2″ MNPT Brass Male Branch Tee 28284

This is a 1/2″ FNPT x 1/2″ MNPT brass male branch tee that measures approximately 2-3/16″ in length, 1-13/16″ tall, and 1-1/8″ wide. This is a T-shaped fitting that is used to connect two male pipe ends to one female pipe end and features NPT threads for a tight seal. Since this is a brass union, it can be used with brass, bronze, copper, steel, aluminum, and iron pipes.

Specifications

• Typical Application: Grease, Fuel, LP and Natural Gas, Refrigeration, Instrumentation, and Hydraulic Systems
• Pipe Size: 1/2″
• Thread Size: 1/2-14
• Operating Pressure: Up to 1200 PSI
• Vibration: Fair Resistance
• Temperature Range: -65°F to +250°F
• Tolerance: +/- .02 on all Dimensions
• Meets specifications and standards of ASA, ASME, and SAE
• Contains Lead

Note: 1/2″ NPT measures about 3/4″ in diameter.

This listing is for one (1) male branch tee.
